| Size: |
1/8-8" |
| Material: |
Carbon steel |
| Connection: |
Thread |
| Technics: |
Forge |
| Application: |
Pipe Connections for matural gas , oil , water, fire fighting, landmines,etc. |
| Origin: |
China |
| Package: |
Cartons& pallet / Cartons& Plywood cases |
| Brand: |
Hongxin |
| Free Sample: |
Yes |
| specification: |
DIN EN 10241 ,Welded or seamless, ASTM A733 / DIN2982 / BS EN10241 |
Introduction to DIN EN 10241 Standard
DIN EN 10241 is a European standard that specifies the requirements for threaded steel pipe fittings, including pipe nipples. These components are critical for creating secure, leak-proof connections in piping systems across various industries, such as oil and gas, chemical processing, water supply, and construction. Pipe nipples manufactured according to this standard ensure compatibility, durability, and safety in high-pressure and high-temperature environments.
As a trusted supplier in China, Cangzhou Hongxin adheres strictly to the DIN EN 10241 standard, delivering precision-engineered steel pipe nipples that meet international quality benchmarks.
Why Choose Cangzhou Hongxin’s DIN EN 10241 Steel Pipe Nipples?
High-Quality Materials: Our nipples are made from premium carbon steel, stainless steel, or alloy steel, offering excellent strength, corrosion resistance, and longevity.
Precision Manufacturing: We utilize advanced machining and threading techniques to ensure accurate dimensions and tight tolerances, complying with DIN EN 10241 specifications.
Comprehensive Size Range: We provide a wide variety of sizes and configurations to meet diverse application needs.
Competitive Pricing: As a direct manufacturer and supplier, we offer cost-effective solutions without compromising quality.
Global Export Experience: We have extensive experience supplying to international markets, ensuring smooth logistics and reliable delivery.
DIN EN 10241 Steel Pipe Nipple Size Chart
Below is a detailed size chart for our DIN EN 10241 compliant steel pipe nipples. All measurements are in millimeters (mm) and inches for convenience.
Nominal Bore
(NB) |
Outside Diameter
(OD) |
Thread Type
(EN 10241) |
Length (L) |
Wall Thickness |
| 1/2" |
21.3 mm |
ISO 228 (G) |
50-200 mm |
2.65 mm |
| 3/4" |
26.9 mm |
ISO 228 (G) |
50-200 mm |
2.65 mm |
| 1" |
33.7 mm |
ISO 228 (G) |
50-200 mm |
3.25 mm |
| 1 1/4" |
42.4 mm |
ISO 228 (G) |
50-200 mm |
3.25 mm |
| 1 1/2" |
48.3 mm |
ISO 228 (G) |
50-200 mm |
3.25 mm |
| 2" |
60.3 mm |
ISO 228 (G) |
50-200 mm |
3.65 mm |
| 2 1/2" |
76.1 mm |
ISO 228 (G) |
50-200 mm |
3.65 mm |
| 3" |
88.9 mm |
ISO 228 (G) |
50-200 mm |
4.05 mm |
| 4" |
114.3 mm |
ISO 228 (G) |
50-200 mm |
4.50 mm |
Notes:
Threads are compliant with ISO 228 (parallel threads, commonly denoted as "G" threads).
Custom sizes and lengths are available upon request.
Materials include carbon steel (e.g., S235JR, S355JR), stainless steel (304, 316), and alloy steel.
Applications of Steel Pipe Nipples
Precision CNC machining and threading
Dimensional verification using calibrated instruments
Pressure testing and surface treatment (e.g., galvanizing, painting)
Compliance with DIN EN 10241, ISO 9001, and other international standards.
How to Order from Cangzhou Hongxin
Select Your Size: Refer to the size chart above or contact us for custom requirements.
Specify Material and Quantity: Choose from carbon steel, stainless steel, or alloy steel.
Request a Quote: Email us at [sales@hxpipefittings.com] with your specifications.
Confirm and Ship: We provide competitive pricing, lead times, and shipping options (FOB, CIF, etc.).
